HP118KWhere to Buy
23 Gauge Headless Pinner Kit
Collation Type: Glue Depth Adjustment: Yes Dry Fire Lockout: true Fastener Length: .5-1.1875 in Fastener Type / Gauge:: 23 Gauge Pin Nails Firing / Acutation Mode: Sequential Jam Clearance: Yes Magazine Angle: Straight Magazine Capacity: 200 Magazine Loading: Side Load No Mar Pad: false Operating Pressure: 70-120 psi Power Source: Pneumatic Tool Height: 11 in Tool Length: 12 in Tool Weight: 2.3 lbs Tool Width: 3 in
- Finish & Trim
- Fine trim work
- Adjustable high/low power control sets pin depth without changing compressor setting
- Low profile nosepiece tapers down to contact point for clear line-of-site
- Lightweight, durable aluminum housing
- Overmoulded grip
- Rear Exhaust
- 19% greater pin capacity over competitive models for a wider range of fasteners
- Kit Includes: Pin Nailer, 1/4" Air Fitting, 500 each of 1/2" Pins, 3/4" Pins, 1" Pins, Case
The 23 Gauge Headless Pinner Kit is covered by our 1-7 Year Limited WarrantyWarranty Details
Frequently Asked Questions
Do you have an MSDS for the Magnalube Teflon grease used in your Nailers?This teflon grease is used in many of our nailers. Please check the attached list or your parts breakdown you can search here to assure yours is on it:
Common O ring kits and trigger valve kits for Bostitch toolsPlease see attachment for common O ring kits (ORK) and trigger valve kits (TVA) for Bostitch tools.
Can I control how deep my BT1855K brad nailer drives the brad?Yes, the tool has a Dial-A-Depth fastener control feature. The fastener control adjustment allows from flush to work surface to shallow or deep countersink.
The DIAL-A-DEPTH™ Fastener control adjustment feature provides close control of the fastener drive depth: from flush with the work surface to shallow or deep countersink.
First set the air pressure for consistent drive in the specific work as described
on page 4, then use the DIAL-A-DEPTH™ fastener control adjustment to give the desired depth of drive.
See attached for further instructions.
Does the HP118K, 23 gauge pinner counter sink the pins deeply?No, this tool is designed to drive the fasteners just below the wood surface.
