MCN250
Where to Buy
35 Degree Metal Connector Framing Nailer STRAPSHOT™
Use this Metal Connector Nailer STRAPSHOT™ with metal framing hardware. Application is quick and precise. It is lightweight and easy to maneuver. Depend on this Metal Connector Nailer strength and durability.
- specs:
-
Collation Type: Paper Dry Fire Lockout: true Fastener Length: 1 1/2 - 2 1/2 in Fastener Type / Gauge:: 35 degree Metal Connector Firing / Acutation Mode: Sequential with Contact Trigger Included Magazine Angle: 35 Degree Magazine Capacity: 53 Magazine Loading: Bottom Load Operating Pressure: 80 - 120 psi Tool Height: 13.25 in Tool Length: 16.5 in Tool Weight: 6 lbs
- Exposed nail tip places fastener point directly into connector holes for a fast and precise application
- In-line magazine offers balance for maneuverability
- Adjustable rafter hook allows user to hang tool on rafters and joists
- Exclusive nail management feature helps to prevent jamming (patent pending)
- Drives 1-1/2" and 2-1/2" STRAPSHOT™ fasteners as well as other paper tape collated metal connector nails
-
The 35 Degree Metal Connector Framing Nailer STRAPSHOT™ is covered by our 1-7 Year Limited Warranty
Warranty Details
Frequently Asked Questions
-
Do you have an MSDS for the Magnalube Teflon grease used in your Nailers?
This teflon grease is used in many of our nailers. Please check the attached list or your parts breakdown you can search here to assure yours is on it: -
Common O ring kits and trigger valve kits for Bostitch tools
Please see attachment for common O ring kits (ORK) and trigger valve kits (TVA) for Bostitch tools. -
How often should I oil my pneumatic tools? Can I add too much?
For the professional that uses the tools every day, the tool should have oil added daily. Just a drop or two a day will assure that the oil keeps the internal components moist and well lubricated.
Too much oil can cause some feeding problems due to the pooling of excess oil in air ports and chambers. This will create worse problems in cold weather because the oil will naturally thicken a bit, slowing the reaction of the moving parts. If you suspect that too much oil is in the tool, prop the tool up with the air fitting pointing downward and allow excess oil to drain into an oil pan. This is usually enough to allow the tool to cycle smoothly again. Avoid oiling for a few days when this action has been taken. Keep in mind that too much oil is far better than not enough. Dry tools can cause many malfunctions and can cause component damage. -
The MCN250 "STRAPSHOT" has a two stick magazine; which is great for load capacity. However, the magazine is too long for certain applications. Does Bostitch supply a smaller magazine?
Yes. The Short Magazine Kit can be order as part #177874. This kit comes with complete instructions for this very simple conversion.
