LPF33PT
Where to Buy
Low Profile Paper Tape Framing Nailer
The 30-degree paper collated Low Profile Framing Nailer features a low profile design for getting in between rafters and tights spaces. The tool-free selectable trigger allows for a single-drive or multi-drive mode with the flip of a switch, and the tool-free depth of drive adjustment is designed for precise sinking of fasteners. This unit has an adjustable rafter hook which allows users to have both hands free when necessary.
- specs:
-
Collation Type: Paper Depth Adjustment: Yes Dry Fire Lockout: true Fastener Length: 2 - 3 1/4 in Fastener Type / Gauge:: 30 Degree Paper Tape Firing / Acutation Mode: Sequential with Contact Trigger Included Jam Clearance: Yes Magazine Angle: 30 Degree Magazine Loading: Bottom Load Operating Pressure: 70 -120 psi Power Source: Pneumatic Tool Height: 4.74 in Tool Length: 20.5 in Tool Weight: 7.6 lbs Tool Width: 12 in
- Low-profile design for getting in-between rafters and in tight spaces
- Internal air filter prevents contaminants from entering the engine
- Tool-free selectable trigger allows for single-drive or multi-drive mode with the flip of a switch
- Tool-free depth of drive adjustment designed for precise sinking of fasteners
- Adjustable rafter hook allows users to hang tool on rafters and joists
- Powerful enough to drive into engineered lumber
- Last nail retention magnet prevents last nail from dropping out of the nose
-
The Low Profile Paper Tape Framing Nailer is covered by our 1-7 Year Limited Warranty
Warranty Details
Frequently Asked Questions
-
How often should I oil my pneumatic tools? Can I add too much?
For the professional that uses the tools every day, the tool should have oil added daily. Just a drop or two a day will assure that the oil keeps the internal components moist and well lubricated.
Too much oil can cause some feeding problems due to the pooling of excess oil in air ports and chambers. This will create worse problems in cold weather because the oil will naturally thicken a bit, slowing the reaction of the moving parts. If you suspect that too much oil is in the tool, prop the tool up with the air fitting pointing downward and allow excess oil to drain into an oil pan. This is usually enough to allow the tool to cycle smoothly again. Avoid oiling for a few days when this action has been taken. Keep in mind that too much oil is far better than not enough. Dry tools can cause many malfunctions and can cause component damage. -
Can the LPF21PL and LPF33PT be used for metal connector applications?
The LPF21PL and LPF33PT cannot be adapted for metal connectors. The F21PL and F33PT are the versions of these framing nailers that can be adapted to use metal connector nails. -
LPF33PT Low Profile Paper Tape Framing Nailer Information Sheet
Please click on the attachment below.
