Bostitch® 20 Gauge Flooring Stapler
This 20 GA Flooring Stapler is designed for fast flooring installation and eliminates the risk of oil stains due to its oil-free operation. Depend on this flooring stapler to prevent floor scratches and for convenience.
- specs:
-
Collation Type: Glue Depth Adjustment: Yes Dry Fire Lockout: false Fastener Length: .5-1 in Fastener Type / Gauge:: 20 GA Staples Firing / Acutation Mode: Sequential Jam Clearance: Tool Free Magazine Capacity: 100 No Mar Pad: true Operating Pressure: 70-120 psi Power Source: Pneumatic Tool Height: 8.25 in Tool Length: 10.13 in Tool Weight: 2.9 lbs Tool Width: 3 in
- Adjustable knobs allow for tool-free adjustment from 1/4" - 1/2" flooring
- High visibility tongue engagement for faster installation and non-marring profile tips to prevent floor scratches
- Oil-free operation requires no regular maintenance and eliminates the risk of oil stains
- Swivel air fitting with internal filter improves maneuverability
- Ultra-quiet rear exhaust directs air away from the user
- Non-marring profile tips to prevent floor scratches
- Rear exhaust directs air away from the user
-
The Bostitch® 20 Gauge Flooring Stapler is covered by our 1-7 Year Limited Warranty
Warranty Details
Frequently Asked Questions
-
Do you have an MSDS for the Magnalube Teflon grease used in your Nailers?
This teflon grease is used in many of our nailers. Please check the attached list or your parts breakdown you can search here to assure yours is on it: -
The small no-mar feet on my Bostitch LHF2025K Flooring Stapler keep falling off and wearing quickly. Is there a fix for this?
Yes, Bostitch has created a Contact Arm Conversion Kit that eliminates the need for the no-mar feet while still offering protection from damage to pre-finished flooring. This kit also improves the ability to slide the tool across the flooring and increases the speed to each cycle and is much easier to operate. The kit part # is 9R195523, if you would like to order, please visit our parts website: http://servicenet.bostitch.com
These tools can also be updated at your nearest Authorized Service Center. Please use the following link to search for the closest one to you: http://www.bostitch.com/servicecenters.asp
-
How many staples will I need to buy to install laminated flooring in an average room?
The product # for the staples used in the 20 gauge flooring stapler, LHF2025K, is SB97-1GLS (1"). Approximately 2,000 staples are required for every 200 sq. ft. of laminated flooring.
